RV750 Series Shark ION™ Robot Vacuum FAQs

Clean out both side wheels, and remove anything stuck around the axle.

1. Push up on the tabs on the brushroll access door, then lift off the door.
2. Remove the brushroll.
3. Clean the brushroll with the provided hair-removal tool.
4. To reinstall, insert the flat end first, then the protruding end, then click brushroll securely into place.
5. Close the brushroll access door and press down until it clicks into place. Push up on the tabs on the brushroll access door, then lift off the door.

For best results, gently dust off cliff sensors and charging pads with a cloth or cleaning brush periodically as needed.

1. With the dust bin out of the unit, clear hair from the Anti-Tangle Comb on the dust bin.

2. Press the filter door release button to open the door and remove the filters.

3. Tap the filters clean or use the included cleaning brush to remove dust trapped between the pleats. The HEPA Filter is NOT Washable.

4. Replace the filters and the filter cover. Close the dust bin and slide it back into the Shark ION ROBOT.

The sensors on your robot's front caster wheel require cleaning to function properly. Check the front wheel frequently and remote any tangled hair or wrapped debris so the wheel can rotate and spin freely.

- To clean, pull out the wheel and the caster from the bottom of the robot.
- Remove debris that may have built up around the shaft and in the wheel cavity.
- Wipe the sensors located in the cavity with a clean, dry towel.
- Pop off the black and white sensor wheel from the caster for easy cleaning.
- Remove any debris built up on the axle.
- Reattach the wheel and reinsert the caster assembly before use.

The side brushes need regular cleaning, as dirt may adhere to them and hair and fibers can easily get tangled in them.

1. Carefully unwind and remove string and hair from side brushes.
2. Gently wipe side brushes with a damp cloth.
3. Be sure to let them air-dry completely before replacing them.

(Wifi Connected Robot only)

Apple:
- Tap on the App Store icon
- Search the Apple App Store for "Shark Clean"
- Tap on the Shark App
- Tap Install on the next page, your installation should begin

Android:
- Tap on the Play Store icon In the Play Store
- Search for "Shark Clean"
- Tap on the Shark App
- Tap install on the Shark App page, your installation should begin

1. Press the dust bin removal latch and slide out the dust bin.
2. Holding it over a trash receptacle, open the dust bin and empty the debris and dust into the trash.
3. The dust bin may be washed for cleaning. Before washing remove the HEPA Filter from the top of the unit.
4. Fully dry the dust bin before replacing the dust bin and reinserting into the robot.

If your robot is stuck, it will make a beeping noise so you can find it.

PREP YOUR HOME FOR CLEANING

To help your robot complete its mission, prep your floor by removing all obstacles, such as loose power cords, clothes, toys, and low-hanging drapes. Use the included BotBoundary Strips to easily block off obstacles or areas you don"t want your robot to enter. See the Tips and Tricks for Great Performance Guide for more information.

You can register your Shark ION™ ROBOT at registeryourshark.com.

CAUTION: Turn off power before performing any maintenance.

When the battery needs replacement, the red "Replace" light will illuminate. To remove the battery, turn the unit over and unscrew the battery cover with a Phillips-head screwdriver. Unplug the old battery from its connector, then plug in the new battery. Replace battery cover and screw it back into place.

Getting started is easy. Follow these simple steps to get cleaning with your Shark ION™.

1. Set up your charging dock. Place the charging dock on a level surface with its back against a wall, in a space without obstructions that can easily be accessed by your Shark ION™. Plug the dock into a power outlet. The more distance in front of the dock without an obstruction, the better-the farther the dock can see, the easier it will be for the robot to return to charge.

2. Install the side brushes. Flip the robot over and snap on the two side brushes included in the box.

3. Power up your Shark ION™. Flip the power switch on the side of your Shark ION™ to the "On"position and place your robot on the dock. Once your robot is fully charged, simply press "Clean"to send your robot into action.

4. Prep your home for cleaning. With Smart Sensor Technology, your robot navigates around obstructions as it cleans your floor. To help your robot complete its mission, prep your floor by removing all obstacles, such as loose power cords, clothes, toys, and low-hanging drapes.

1. Cut the BotBoundary strip to the desired length (18" minimum) so it covers the entire perimeter of an object or spans the length of the doorway you"d rather your robot not cross.

2. Simply lay the BotBoundary strip flat on the floor or under an area rug. For best results, make sure your BotBoundary strip is completely flat against the floor.

3. With the provided connectors, you can create angles to customize the BotBoundary strips to fit your home. When setting up your BotBoundary strips it is useful to either make a closed loop around an object using the included connectors or to place them between fixed objects, like door frames or the legs of a couch.

To enable the Shark Skill for Amazon Alexa: the Shark Skill for Amazon Alexa:

1. Open the Amazon Alexa app, go to the menu and select Skills. Or, go to the Alexa Skills store on the Amazon website.

2. Search for the "Shark Skill"

3. Select the "Shark Skill" to open the detail page. Then select the Enable Skill option. After enabling the skill, you can ask Alexa to open and use it by saying "open Shark Skill"

Your Shark ION™ ROBOT is designed with Smart Sensor Technology so it can navigate around obstructions as it cleans your floor. By using an array of sensors, the Shark ION™ will steer itself around your home, using walls and objects as its guide and gently bumping them. This method allows the robot to travel in and out of rooms and around obstacles.

If your Shark ION™ ROBOT appears to be spending a lot of time in one spot, don't worry-over time, its programming will help it cover the full area. The Shark ION™ might not hit every area in one cleaning, but by scheduling daily cleaning, you'll notice its cleaning path will differ with each run to ensure it is maintaining your floors.

Your Shark ION™ needs about 3 hours to fully charge.

A typical cleaning cycle for your Shark ION™ will last about 1 hour.

CAUTION: Turn off power before performing any maintenance.

- Main Brushroll - Every 6-12 months
- Side Brushes - When visibly worn
- Dust Bin Filter - Every 2 months
- Front Caster Wheel - Every 12 months
- Brushroll Door - Every 12 months
- Battery - when directed by the "replace battery" light on the robot

When you want to send your robot back home, simply press the Dock button on the robot or remote.

If there is a clog, the robot will detect that its suction motor is working harder than usual. First, remove and empty the dust bin. Press the filter door release button, open the door and remove the filter. Clean the dust bin and filter with a cleaning brush. Next, turn the unit over and remove the brushroll. Look into the inlet to see if anything might be stuck, and remove any obstructions.

Pick up the Shark ION™ ROBOT to free it from whatever it is stuck on. Press the bumper back a few times, making sure it moves freely and isn't locked in a position where it's pressed back.

During your first few cleanings, you may need to make some small adjustments to optimize your robots performance.

1. Always prep your home before cleaning. Some furniture or loose cords may create problems for your robot. To prevent this, clear away cords and other obstructions. If an obstruction can't be moved, block off the area with the included BotBoundary strips.

2. Your robot may find its way under furniture with low clearance, but not be able to free itself. Try using BotBoundary strips to block problem areas. Consider shifting furniture away from carpets or using furniture pads to raise the furniture to create clearance. Your robot can easily climb over obstacles up to 3/4"high. Obstructions higher than this may present a challenge. Use BotBoundary strips to block off these areas.

3. Your robot is designed to run for 60 minutes before searching for its dock. If your robot roams too far, it may have trouble finding the dock. Make sure the dock is centrally located, with 3 feet of clearance on either side. Depending on the size of your floor space, it may be helpful to use BotBoundary strips to keep your robot from traveling too far. You can also add a second dock, available at www.sharkaccessories.com

Unwind anything that is wrapped around the brushroll. Remove the brushroll from the unit by lifting off the brushroll access door, then pulling out the brushroll. Use scissors or the cleaning tool provided with your unit to cut away any debris or hair.

The brown strips included in the box with your robot are called BotBoundary strips and they are used to quickly and easily create "no-go zones" to keep your robot out of the areas you would like it to avoid. These may include: - Near power cords that might cause tangles - Hallways where you"d rather your robot not travel - Around furniture with low clearance that may trap your robot

0.4 dry quarts to the MAX FILL line

Your Shark ION™ ROBOT may be losing connectivity for two reasons: the Wi-Fi signal may be weak, or the robot may have entered a zone that blocks Wi-Fi. It is normal for your robot to temporarily lose connectivity when it goes under couches or moves through parts of your house that are far from your router. Your Shark ION™ ROBOT will automatically reconnect to Wi-Fi.

Please fully charge your robot before using it for the first time (~3hrs) Once fully charged please unplug the dock and run the robot until it run out of charge. Then plug in the dock, charge fully and run the robot normally.

CAUTION: Turn off power before performing any maintenance.

Recommended Cleaning Schedule:

-Dust Bin - Empty after each use
-Main Brushroll - Check weekly
-Dust Bin Filter - Clean weekly
-Front Caster Wheel - remove and clean weekly

If your robot is kicked or pushed off of its dock or the power goes out the robot may attempt to locate the dock, if the robot is unable to find the dock within 30 seconds it will turn itself off.

Your robot is in the final stages of its docking routine and is making sure it aligns with the charging pads on the dock.

The robot may struggle with some high pile carpets. If your robot continues to have issues with the area, try to use the included BotBoundary strips to block off the area. You may purchase additional BotBoundary strips from sharkaccessories.com

Your Shark ION ROBOT was designed with Smart Sensor Navigation that prevents it from falling down stairs. The robot will sense the stairs and change direction to avoid any drops or falls.

Turn the unit over and pull off the side brushes. Remove any debris wrapped around the side brushes.

With recharge and resume, your robot will return to its base, recharge, and can pick up cleaning from where it left off.
